Bike handlebars come in varying designs. Removal of the handlebars will depend on the assembly your bike carries. Newer bikes have a threadless stem for easy height adjustment. Older units will have a stem secured with a locknut that requires a wrench to adjust the height of the handlebars. To tell the difference, sit on your bike and look at the stem that connects the handlebars to the frame. If the locknut does not turn by hand, your bike has a threaded headset. Regardless of the style bike, removal of the handlebars is not difficult and should take just a few minutes.
Threaded Headset
Step 1
Disconnect any cables attached to the handlebars. Often this means hand brakes and gear shifts. Use a screwdriver or Allen wrench to detach the cables or remove the brackets.
Step 2
Turn the locknut counterclockwise until the handlebars move. The locknut sits on the stem that connects the handlebars to the bike frame. Use an adjustable wrench to turn the locknut.
Step 3
Pull up on the handlebars until them come free from the bike frame.
Threadless Headset
Step 1
Disconnect cables or attachments to the handlebars with a screwdriver or Allen wrench.
Step 2
Locate the faceplate the sits on the fork where the handlebar stem bends to meet the bike frame. Unscrew the bolt holding the faceplate to the stem. Set the bolt and faceplate aside.
Step 3
Pull up on the top portion of the handlebars to lift them off the stem assembly.
Step 4
Turn the locking flat that secures the stem to the bike frame. This piece requires no wrench. Grasp the flat with your hand and turn it counterclockwise. Pull up on the stem to remove it from the frame if necessary.
Tips and Warnings
- If any of the bolts or locknuts stick, spray them with a lubricant, wait five minutes and try again.
Things You'll Need
- Screwdriver
- Allen wrench
- Adjustable wrench
