How to Set Up an Omron Pedometer

author image Nicole Vulcan
Nicole Vulcan has been a journalist since 1997, covering parenting and fitness for The Oregonian, careers for CareerAddict, and travel, gardening and fitness for Black Hills Woman and other publications. Vulcan holds a Bachelor of Arts in English and journalism from the University of Minnesota. She's also a lifelong athlete and is pursuing certification as a personal trainer.
How to Set Up an Omron Pedometer
A man is tying his laces while wearing a fitness tracker. Photo Credit: Kuzmik_A/iStock/Getty Images

When you're aiming to lose weight or just get in better shape, walking can be one way to do it, whether it be walking on a treadmill or going out for a stroll on your lunch break. But if you want to get a sense of how much walking you're doing throughout the day, you may want to use a pedometer. Like most pedometers, the Omron brand pedometer requires you to enter in some basic information before use, so that you'll get a more accurate reading of the steps you've taken.

Video of the Day

Measure Stride Length

Step 1

Draw a chalk line on the ground and then set the back of one foot against the line.

Step 2

Walk 10 steps, using your normal stride length, and then make a mark at the front of your toe after the 10th step.

Step 3

Measure the distance between the two marks in inches.

Step 4

Divide the number by 10 to arrive at your stride length. Then convert that number to feet and inches, keeping in mind that 12 inches represents 1 foot. For example, if your stride length was 16 inches, you'd represent that number as 1 foot 4 inches.

Enter Your Information

Step 1

Put a fresh battery into the device by removing the back cover with a small screwdriver, pulling out the old battery with a thin stick and then setting a new battery in the battery slot with the "+" side facing upward. Replace the battery cover and tighten the screw. This will cause the device to turn on and display a flashing time indicator in the bottom left corner of the screen. If you don't need to replace the battery yet, you'll still need to remove the battery, as that is how you refresh the data on the device.

Step 2

Press the "Memo/up arrow" button to move up to the current hour. Look at the AM/PM indicator to the left of the time and set the time to the correct time of day. Press "Set" when the correct hour is displayed. Then press the "Memo/up arrow" button again to set the minutes to the correct time. Press "Set" when the correct minute is displayed. Following that, the weight indicator will flash in the top right corner of the screen.

Step 3

Press the "Memo/up arrow" button until your correct weight, in pounds, appears on the screen. Then press the "Set" button to set that weight. Following that, the stride length indicator will display in the top right corner of the screen.

Step 4

Press the "Memo/up arrow" button until the correct stride length is indicated on the screen, in feet and inches. If your stride length was 16 inches, you should have 1.04 displayed on the screen. Press "Set" when you've arrived at the correct number.

Step 5

Clip the pedometer onto your belt or put it in a front pocket to begin counting your steps.
