How to Repair the Magnetic Resistance for Exercise Bikes

It's time to do some troubleshooting if you find that your magnetic resistance exercise bike is not working. As the name implies, magnetic resistance exercise bikes use a magnetic field to create resistance. The field is generated by electrical circuit or by internal batteries and pedaling action.

Magnetic resistance exercise bikes use a magnetic field (Image: Eugenio Marongiu/Cultura/GettyImages)

A control panel is used to adjust resistance by altering the intensity of the magnetic field. Most upright exercise bikes have a magnetic unit that interacts with the metallic surface on the flywheel to provide the positive and negative poles.

Chain drive recumbent exercise bikes have sensors on the flywheel and pedal cranks that generate magnetic poles. It's advisable to review the warranty conditions before attempting to fix magnetic resistance exercise bike problems.

Fixing Upright Exercise Bike Problems

If you have questions while troubleshooting your upright bike, contact customer service as indicated in your user's manual.

Step 1: Replace Display Panel Batteries

Unplug the power cord from the electrical outlet. If the unit is battery powered, begin by replacing the batteries in the display panel and re-test the bike. Use an Allen wrench or Phillips screwdriver to remove the bolts that secure the split flywheel covers.

Step 2: Remove Pedal Cranks and Flywheel Covers

Pull each cover to the side to expose the flywheel. Grip the flywheel and rotate the pedal cranks counterclockwise to unseat them from the internal pulley. Remove the cranks and set them aside. Remove the flywheel covers.

Step 3: Remove and Replace Magnetic Unit

Use a socket and ratchet to remove the nut on the pulley. Twist the pulley to the side and slip the V-belt off the pulley and the magnetic unit. Inspect the belt for damage and replace if necessary. Remove the nut that secures the magnetic unit. Remove and replace the magnetic unit.

Step 4: Reinstall V-Belt and Pedal Cranks

Reinstall the V-belt on to the magnetic unit and pulley. Replace the nut that secures the pulley. Position the flywheel covers on each side of the flywheel. Reattach the pedal cranks by rotating them clockwise as you thread them into the pulley from each side. Reattach the flywheel covers.

Fixing Recumbent Exercise Bike Problems

Refer to your user's manual for specific troubleshooting tips if your recumbent magnetic exercise bike isn't working.

Step 1: Locate Hub Sensor Battery Pack

Remove the chain guard using an Allen wrench or Phillips screwdriver to loosen the bolts that secure the guard in place. Set the guard aside. Rotate the flywheel until the hub sensor battery pack is visible.

Step 2: Replace the Batteries

Inspect the insulated wire leads at the connection on the unit. If the leads are intact and not burned, it's not necessary to replace the unit. Remove the cap from the battery pack with a screwdriver. Replace the batteries and reattach the cap to the unit.

Step 3: Loosen the Speed Sensor Unit

Locate the speed sensor unit near the pedal sprocket. Use a hex wrench to remove the nut that holds the sensor in place. Pull the speed sensor out just enough to access the battery cap on the inside of the unit.

Step 4: Reinstall Speed Sensor and Chain Guard

Remove the battery cover, install a new battery and replace the cap. Reinstall the speed sensor and reattach the nut that holds it in place. Reattach the chain guard and tighten the bolts that hold it in place.

Tip

A voltage meter is used to troubleshoot problems with internal electrical circuits.
