The Difference Between Parallel Hybrid Cars & Series Hybrid Cars

Electric car in charging
A hybrid car is plugged into an outlet. (Image: omada/iStock/Getty Images)

Hybrid electric vehicles--HEVs--combine a gasoline-powered combustion engine with an electric motor to offer a more environmentally-friendly driving experiences. Hybrid cars are classified according to the type of drivetrain or powertrain they feature, which determines how the engine and the motor work together to power the car. Parallel hybrids and series hybrids represent opposite ends of the spectrum and there are several key differences between these two types of hybrid drivetrains.

Features

While both parallel and series hybrids feature a gasoline engine, electric motor, rechargeable battery, inverter and transmission, they are configured in uniquely different ways. According to Hybrid Center, the engine in a series hybrid is smaller than a parallel hybrid while the electric motor and battery are larger. Series hybrids feature a separate generator which is connected to the engine. In a parallel hybrid, the electric motor acts as a generator. In a series hybrid, the gasoline engine is not coupled directly to the wheels, while it is in a parallel hybrid.

Parallel Hybrid Propulsion

In a parallel hybrid, both the electric motor and the combustion engine work together to power the vehicle. According to the U.S. Department of Energy (DOE), the gasoline engine and the electric motor are both connected to the transmission. When fuel travels to the engine or when the electric motor is turned on, the power that is generated propels the car. A controller in the transmission determines when to operate the electric motor and when to switch to the gasoline engine.

Series Hybrid Propulsion

In a series hybrid, the electric motor is solely responsible for turning the vehicle's wheels. According to Hybrid Center, the electric motor is charged by the battery pack or by the generator, which is powered by the gasoline engine. The gasoline engine in a series hybrid is not coupled to the wheels and does not directly power the car. A controller in the transmission determines how much power is needed to propel the vehicle and whether to pull it from the battery or the generator.

Regenerative Braking

Both parallel and series hybrids feature a regenerative braking system, which both slows the car and recharges the battery. In a regenerative braking system, the electric motor helps to slow the car down as you press the brake, according to the U.S. Department of Energy. The energy that is released from the wheels turns the electric motor, which acts as a generator and sends electricity back to the battery.

Efficiency

The efficiency of parallel and series hybrids varies according to the conditions under which they're driven. According to Hybrid Center, the composition of parallel hybrids makes them more efficient for highway driving at higher, more constant speeds. Conversely, series hybrids are more efficient for driving in the city because their drivetrain structure reduces the strain on the engine in stop-and-go driving situations.
